A5120 51.2V 5.12KWH Rack Mounted Lithium Battery

1. Cycle life：>6000 Cycles @ 90%DOD.

3. 2U Thickness：88mm: Lager capacity in limited space Multi installation methods.

4. Intelligent BMS：Wider compatibility.

5. Auto-heating function：Heating below 0℃,BMS automatic management.

6. Consistency of battery cells ：Active equalization (3A) Settable charging voltage.

6. Scalable: paralleled 16 sets：Battery: 5.12kWh; Cabinet: 51.2kWh;Paralled 6 cabinets 307.2kWh.

7. Car-grade LiFePo4 battery：Compact, safe, stable, flexible.

8. Customizable：Indoor or outdoor cabinets as request.

9. Safety Standard：CUL1973/UL1973/CE/IEC62619/UN38 .3.

Data Sheet

User Manual

Model	A5120
Certificate Model	YNJB16S100KX - L
Nominal Voltage	51.2V
Voltage Range	44.8V~57.6V
Nominal Capacity	100Ah
Nominal Energy	5.12kWh
Charge Current	50A
Max Charge Current	100A
DischargeCurrent	50A
Max Discharge Current	100A
Charge Temperature	0°C ~ +55°C
Discharge Temperature	-20°C ~ +55°C
Battery Equalization	Active 3A
Heating Function	BMS automatic management when charging temperature below 0 (Optional)
Relative Humidity	5% - 95%
Dimension(LWH)	49660088mm
Weight	43±0.5KG
Communication	CAN, RS485
Enclosure Protection Rating	IP20
Cooling Type	Natural Cooling
Cycle Life	6000
Recommend DOD	90%
Design Life	20+ Years (25°C @ 77°F )
Safety Standard	CUL1973/UL1973/CE/IEC62619/UN38 .3
Max. Pieces of Parallel	16
